税込価格:¥374,000
FEATURE:| Frame | AL6 SLOPE STYLE, 100MM TRAVEL, POSTMOUNT 160MM |
|---|---|
| Fork | ROCKSHOX PIKE DJ, TRAVEL 100MM, TAPERED STEERER |
| Rear Shock | ROCKSHOX MONARCH R, 7.5”X2.00”(190X51MM), M8X22MM |
| Head Set | ZS 44/28.6 | ZS 56/40 |
| Stem | ALLOY E:40MM R:0DEG BB:31.8MM |
| Handlebar | ALLOY W:750MM R:38.1MM BB:3.18MM |
| Rear Derailleur | SRAM RD-GX-1DH-A3 DA |
| Shifter | SRAM SL-GX-DH-A2 7-SPEED |
| Bottom Bracket | SAMOX INTEGRATED BB BSA |
| Crank Set | SAMOX TAF15-D32A 32T, 170MM |
| Cassette | SRAM PG-720 7-SPEED 11-25T |
| Chain | KMC X11 |
| Pedal | - |
| Brake | SHIMANO BR- MT501 |
| Wheel Set | ALLOY DOUBLE WALL W/ ALLOY HUB 6-BOLT |
| Tire | VEE XCV, 26”X2.25” |
| Saddle | POLYGON PIVOTAL SADDLE |
| Seat Post | ALLOY, PIVOTAL, 30.9X200MM |
| Wheel Size | 26" |
| Color | BLACK BRONZE |
| Weight | 15.41 KG |
| A | B | C | D | E | F | G | H | I | J | K | L | M | |
| Size | Seat Tube Length | Seat Tube Angle | Effective Seat Tube Angle | Head Tube Length | Head Tube Angle | Effective Top Tube | BB Height | BB Offset | Chainstay Length | Wheelbase | Frame Reach | Frame Stack | Standover Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| All Size | 330 | 70 | 75 | 120 | 69 | 575 | 331 | 8 (Drop) | 400 | 1079.1 | 425 | 558.5 | 649 |
| 140 | 145 | 150 | 155 | 160 | 165 | 170 | 175 | 180 | 185 | 190 | cm | |
| S |
※商品仕様、カラーその他は、予告なく変更される可能性があります
