税込価格:¥179,300
FEATURE:| MODEL NAME | STRATTOS S4 |
|---|---|
| MODEL CATEGORY | RACING BIKES, ALLOY, TIAGRA 20 SP |
| SIZE (CT) | S/M/L |
| COLOR | BLACK/BLUE |
| FRAME | ALX PERFORMANCE ROAD, 130MM O.L.D., INTERNALROUTE |
| FORK | ACX PERFORMANCE ROAD, TAPER ALLOY STEERER |
| HANDLERBAR | ENTITY SPORT, ALLOY, 400MM(S, M), 420MM(L) |
| STEM | ENTITY SPORT, ALLOY, 90MM(S), 110MM(M, L) |
| HEADSET | FSA NO.42/ACB, TAPER ID: 42/52MM |
| SADDLE | ENTITY, STEEL RAIL |
| SEATPOST | ENTITY SPORT, ALLOY, 27.2X350MM |
| CRANKSET | SHIMANO TIAGRA FC-4700 50X34T 170MM(S, M) 172.5MM(L) |
| BOTTOM BRACKET | SHIMANO INTEGRATED BB BSA |
| CHAIN | KMC X-10 |
| CASSETTE SPROCKET | SHIMANO CS-HG500, 10-SPEED 12-28T |
| FRONT DERAILLEUR | SHIMANO TIAGRA FD-4700-F |
| REAR DERAILLEUR | SHIMANO TIAGRA RD-4700-SS |
| SHIFTING LEVER | SHIMANO TIAGRA ST-4700 |
| BRAKE LEVER | INTEGRATED WITH SHIFTER |
| BRAKE | SHIMANO TIAGRA BR-4700 |
| TYRE | PERFORMANCE TIRES, 700X28C |
| WHEELSET | ALLOY DOUBLE WALL RIMS WITH ALLOY HUB 28H |
| WEIGHT | 9.6 KG (SIZE MEDIUM) |
| A | B | C | D | E | F | G | H | I | J | K | L | M | |
| Size | Seat Tube Length | Seat Tube Angle | Effective Seat Tube Angle | Head Tube Length | Head Tube Angle | Effective Top Tube | BB Height | BB Offset | Chainstay Length | Wheelbase | Frame Reach | Frame Stack | Standover Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 470 | 74.5 | 74.5 | 105 | 72.5 | 525 | 272 | 72.5 Drop | 415 | 977.32 | 383.5 | 510.3 | 715.7 |
| M | 500 | 74 | 74 | 130 | 73 | 540 | 274.5 | 70 Drop | 415 | 984.83 | 387.1 | 533.3 | 746.5 |
| L | 520 | 73.5 | 73.5 | 155 | 73 | 555 | 268 | 70 Drop | 415 | 994.01 | 390 | 557.2 | 767.1 |
| 140 | 145 | 150 | 155 | 160 | 165 | 170 | 175 | 180 | 185 | 190 | cm | |
| S | ||||||||||||
| M | ||||||||||||
| L |
※商品仕様、カラーその他は、予告なく変更される可能性があります
